NEW HIT PVC White

SkyFens SkyLight PLUS TERMO | PVC, high pivot, 2-glass roof window from the Swiss Arbonia Group

✔ PVC ✔ high-pivot ✔ 2-panes ✔ Window U-value: 1.3 W/m²K ✔ Glazing U-value: 1.1 W/m²K
Alter Preis: 355,30 ( 298,57 excl. VAT and shipping)
248,71 inc. VAT, excl. shipping
(209,00 excl. VAT and shipping) You save: 89,57 (30%)
The size refers to the outer dimension of the roof window!!!
SKY-S+TB-0507-S

Ships within 3-5 business days after receipt of your payment

+

Additional products

Skyfens Supro Flashing F for a profiled roofing material Skyfens Supro Flashing F for a profiled roofing material
The size refers to the outer dimension of the roof window!!!
50,97 inc. VAT, excl. shipping (42,83 excl. VAT and shipping)
+

Ships within 20 business days after receipt of your payment

Skyfens Supro Flashing P for flat coverings Skyfens Supro Flashing P for flat coverings
The size refers to the outer dimension of the roof window!!!
50,97 inc. VAT, excl. shipping (42,83 excl. VAT and shipping)
+

Ships within 20 business days after receipt of your payment

Air permeable underfelt collar for roof windows Air permeable underfelt collar for roof windows
The size refers to the outer dimension of the roof window!!!
19,99 inc. VAT, excl. shipping (16,80 excl. VAT and shipping)
+

Ships within 1-3 business days after receipt of your payment

XT insulation band for roof windows XT insulation band for roof windows
The size refers to the outer dimension of the roof window!!!
29,99 inc. VAT, excl. shipping (25,20 excl. VAT and shipping)
+

Ships within 1-3 business days after receipt of your payment

  • Total cost 248,71

Add to wish list

The SkyLight Plus Thermo roof window is an improved production line of the already very popular SkyLight roof window. The Uw value achieved for the entire roof window is now Uw=1,3W/m2K,meeting the more stringent requirements for minimum heat transfer coefficients for the building envelope. By using a warm spacer, a Ug value of Ug=1,1W/m2K is achieved.

Technical data of the SkyLight Plus Thermo roof window

  • New, improved profile in combination with 2-glass glazing guarantees a balanced ratio of energy loss. Uw coefficient of 1.3 W/mK.
  • A package of four special seals prevents leaks and contributes to a higher level of thermal insulation of the window
  • The raised 3/4 pivot improves the view out of the window and allows free access to the window space.
  • Easier installation of flashings thanks to extended grooves in the frame. Angle brackets increase the adjustment range of the installed window.
  • The window is equipped with an innovative frame hinge that increases the safety, durability and functionality of the window for many years to come
  • A system of four cold-resistant seals ensures excellent sealing of the Skylight Plus Termo roof window.
  • The outer flashing of a roof window protects the hardware from the weather and improves the sealing of the frame-sash connection.
  • Installation of windows in all types of roofs with a roof pitch of 15-70 degrees
  • It requires no special maintenance. Maintenance is limited to cleaning the windows.
  • Convenient position for cleaning the outside of the window - the sash rotates up to 120 °
  • The handle is located in the lower part of the window sash
  • Package with four special seals Prevents leaks and contributes to greater thermal protection for your window.
  • Warm frame Improves heat transfer parameters.
  • Micro-drains allow condensation to drain to the outside. Thanks to this solution, we reduce the amount of condensed water vapor that is discharged to the outside. The window is more resistant to unfavorable weather conditions.
  • SKYLIGHT windows are made of PVC reinforced with steel cores. The PVC material is dirt-repellent, maintenance-free, does not fade and does not change shape when exposed to moisture. Our window has a longer service life without the need for costly replacements and upgrades.

Standard window sizes:

5/7 5/9 5/11 6/9 6/11 6/14 7/9 7/11 7/14 7/16 9/11 9/14 11/11 11/14
550x780 550x980 550x1180 660x980 660x1180 660x1400 780x980 780x1180 780x1400 780x1600 940x1180 940x1400 1140x1180 1140x1400

We offer the option of custom-made roof windows in any size between our smallest and largest standard model to ensure a perfect fit for individual projects

SkyFens window comparison:

  SkyLight SkyLight PLUS TERMO Skylight SUPRO TRIPLE SkyLight SUPRO TRIPLE TERMO

Uw 1,4 W/m2K 1,3 W/m2K 1,2 W/m2K 1,1 W/m2K
Ug 1,1 W/m2K 1,1 W/m2K 05,5 W/m2K 0,5 W/m2K
Glazing Single chamber (double glazing) Single chamber (double glazing) Double chambers (triple glazing) Double chambers (triple glazing)
Sound insulation 33 dB 31 dB 32 dB 32 dB
Air permeability Class 3 Class 3 Class 4 Class 4
Water tightness class Class E1050 Class E1200 Class E1200 Class E1200
Resistance to wind loads Class C3 Class C4 Class C4 Class C4
Space between panes filled with inert gas: Argon Argon Argon Argon
Outside panes: 4 mm, ESG 4 mm, ESG 4 mm, ESG 4 mm, ESG
Interior panes: 4 mm 4 mm 4 mm 4 mm
Total thickness of the glass package: 24 mm 28 mm 48 mm 48 mm
Exterior color: Gray, RAL 7043 Gray, RAL 7043 Gray, RAL 7043 Gray, RAL 7043
Installation in roof pitch: 15-70° 15-70° 15-70° 15-70°
Warranty: 10 years 10 years 10 years 10 years

Roof windows

Material:
  • PVC
Opening:
  • high-pivot
Glazing:
2-panes
Window U-value:
1.3 W/m²K
Glazing U-value:
1.1 W/m²K
Control:
Manuall

VELUX glazing technical data

Glazing (--51) (--61) (--64) (--70) (--68) (--66) (--62) (--62D) (--67) (--69) (--70Q) (--82) (--15)
Thermal transmittance
W/m2K
1.0 0.6 0.6 1.0 0.7 0.6 0.5 1.0 0.5 0.7 1.0 0.3 0.7
Amount of
chambers
1 2 2 1 2 2 2 1 2 2 1 4 2
Warm TGI spacer
Inert gas
filled panes
Argon Argon Argon Argon Argon Argon Krypton Krypton Krypton Argon Argon Krypton Argon
Toughened
outer pane
Laminated opaque
inner pane
X X X
Safety class X X X P2A P2A P2A P2A P2A P2A P2A P4A P2A P2A
Ornamental X X X X X X X X X X X X X
Enhanced noise
reductiont
X X X X X X
Easy-to-clean
coating
X X X X X X X X X
Anti-dew effect X X X X X X X
